Why Custom ChatGPT is so Powerful and Versatile

I believe we have all tested ChatGPT, and probably like me, you have been impressed by its remarkable capabilities. However, ChatGPT has a significant limitation: it can only answer questions and perform tasks based on the public knowledge base it was trained on.

Imagine having a chatbot based on ChatGPT that communicates effectively and truly understands the nuances of your business, sector, or even a particular topic of interest. That’s the power of a custom ChatGPT. A tailor-made chatbot allows for specialized conversations, providing the needed information and drawing from a unique database you’ve developed.

This becomes particularly beneficial in industries with specific terminologies or when you have a large database of knowledge that you want to make easily accessible and interactive. A custom ChatGPT, with its personalized and relevant responses, ensures a better user experience, effectively saving time and increasing productivity.

Let’s delve into how to build such a solution. Spoiler it does not work by putting all the content into the prompt. But there is a great alternative.

Understanding the Building Blocks of Custom ChatGPT with Retrieval Augmented Generation

The foundational technology behind ChatGPT is OpenAI’s Generative Pre-trained Transformer models (GPT). These models understand language by predicting the next word in a sentence and are trained on a diverse range of internet text. However, the GPT models, such as the GPT-3.5, have a limitation of processing 4096 tokens at a time. A token in this context is a chunk of text which can be as small as one character or as long as one word. For example, the phrase “ChatGPT is great” is four tokens long.

Another challenge with Foundation Models such as ChatGPT is that they are trained on large-scale datasets that were available at the time of their training. This means they are not aware of any data created after their training period. Also, because they’re trained on broad, general-domain datasets, they may be less effective for tasks requiring domain-specific knowledge.

How Retrieval Augmented Generation (RAG) Helps

Retrieval-Augmented Generation (RAG) is a method that combines the strength of transformer models with external knowledge to augment their understanding and applicability. Here’s a brief explanation:

To address this, RAG retrieves relevant information from an external data source and uses this information to augment the input to the foundation model. This can make the model’s responses more informed and relevant.

Data Sources

The external data can come from various sources like databases, document repositories, or APIs. To make this data compatible with the RAG approach, both the data and user queries are converted into numerical representations (embeddings) using language models.

Data Preparation as Embeddings

The embeddings, which are essentially vectors, need to be stored in a database that’s efficient at storing and searching through these high-dimensional data. This is where Azure’s Cosmos Mongo DB comes into play. It’s a vector search database specifically designed for this task.

To circumvent the token limitation and make your extensive data available to ChatGPT, we turn the data into embeddings. These are mathematical representations of your data, converting words, sentences, or documents into vectors. The advantage of using embeddings is that they capture the semantic meaning of the text, going beyond keywords to understand the context. In essence, similar information will have similar vectors, allowing us to cluster related information together and separate them from a semantically different text.

Storing the Data in Vector Databases

The embeddings, which are essentially vectors, need to be stored in a database that’s efficient at storing and searching through these high-dimensional data. This is where Azure’s Cosmos Mongo DB comes into play. It’s a vector search database specifically designed for this task.

Matching Queries to Knowledge

The RAG model compares the embeddings of user queries with those in the knowledge base to identify relevant information. The user’s original query is then augmented with context from similar documents in the knowledge base.

Input to the Foundation Model

This augmented input is sent to the foundation model, enhancing its understanding and response quality.

Updates

Importantly, the knowledge base and associated embeddings can be updated asynchronously, ensuring that the model remains up-to-date even as new information is added to the data sources.

In sum, RAG extends the utility of foundation models by incorporating external, up-to-date, domain-specific knowledge into their understanding and output.

By incorporating these components, you’ll be creating a robust custom ChatGPT that not only understands the user’s queries but also has access to your own information, giving it the ability to respond with precision and relevance.

Ready to dive into the technicalities? Stay tuned!

How to Set Up Vector Search in Cosmos DB

First, you must understand that you will need a database to store the embeddings. It does not necessarily have to be a vector database. Still, this type of database will make your solution more performant and robust, particularly when you want to store large amounts of data.

Azure Cosmos DB for MongoDB vCore is the first MongoDB-compatible offering to feature Vector Search. With this feature, you can store, index, and query high-dimensional vector data directly in Azure Cosmos DB for MongoDB vCore, eliminating the need for data transfer to alternative platforms for vector similarity search capabilities. Here are the steps to set it up:

1. Choose Your Azure Cosmos DB Architecture: Azure Cosmos DB for MongoDB provides two types of architectures, RU-based and vCore-based. Each has its strengths and is best suited for certain types of applications. Choose the one that best fits your needs. If you’re looking to lift and shift existing MongoDB apps and run them as-is on a fully supported managed service, the vCore-based option could be the perfect fit.
2. Configure Your Vector Search: Once your database architecture is set up, you can integrate your AI-based applications, including those using OpenAI embeddings, with your data already stored in Cosmos DB.
3. Build and Deploy Your AI Application: With the Vector Search set up, you can now build your AI application that takes advantage of this feature. You can create a Go app using Azure Cosmos DB for MongoDB or deploy Azure Cosmos DB for MongoDB vCore using a Bicep template as suggested next steps.

Azure Cosmos DB for MongoDB vCore’s Vector Search feature is a game-changer for AI application development. It enables you to unlock new insights from your data, leading to more accurate and powerful applications.

Cosmos DB for Mongo DB Usage Models

Regarding Cosmos DB for Mongo DB, there are two options to choose from: Request Unit (RU) Database Account and vCore Cluster. Each option follows a different pricing model to suit diverse needs.

The Request Unit (RU) Database Account operates on a pay-per-use basis. With this model, you are billed based on the number of requests and the level of provisioned throughput consumed by your workload.

As of 27th Mai 2023, the brand new vector search function is only available for the vCore Cluster option, which is why we will use this setup for this tutorial. The vCore Cluster offers a reserved managed instance. Under this option, you are charged a fixed amount on a monthly basis, providing more predictable costs for your usage.

Once you have created your vCore instance, you must collect your connection string and make it available to your Python script. You can do this either by storing it in Azure Key Vault (which I would recommend) or by storing it locally on your computer or in the code (which I would not recommend for obvious security reasons).

Using other Vector Databases

While Cosmos DB is a popular choice for vector databases, I would like to note that other options are available in the market. You can still benefit from this tutorial if you decide to utilize a different vector database, such as Pinncecone or Chroma. However, it is necessary to make code adjustments tailored to the APIs and functionalities of the specific vector database you choose.

Specifically, you will need to modify the “insert embedding functions” and “similarity search functions” to align with the requirements and capabilities of your chosen vector database. These functions typically have variations that are specific to each vector database.

By customizing the code according to your selected vector database’s API, you can successfully adapt the tutorial to suit your specific database choice. This allows you to leverage the principles and concepts this tutorial covers, regardless of the vector database you opt for.

Also: Vector Databases: The Rising Star in Generative AI Infrastructure

Prerequisites

Before diving into the code, it’s essential to ensure that you have the proper setup for your Python 3 environment and have installed all the necessary packages. If you do not have a Python environment, follow the instructions in this tutorial to set up the Anaconda Python environment. This will provide you with a robust and versatile environment well-suited for machine learning and data science tasks.

In this tutorial, we will be working with several libraries:

• openai
• pymongo
• PyPDF2
• dotenv

Should you decide to use Azure Key Vault, then you also need the following Python libraries:

• azure-identity
• azure-key-vault

You can install the OpenAI Python library using console commands:

• pip install openai
• conda install openai (if you are using the Anaconda packet manager)

Step #1 Authentification and DB Setup

Let’s start with the authentification and setup of the API keys. After making necessary imports, the code gets things read to connect to essential services – OpenAI and Cosmos DB – and makes sure it can access these services properly.

1. Fetching Credentials: The script starts by setting up a connection to a service called Azure Key Vault to retrieve some crucial credentials securely. These are like “passwords” that the script needs to access various resources.
2. Setting Up AI Services: Then, it prepares to connect to two different AI services. One is a version that’s hosted by Azure, and the other is the standard, public version.
3. Establishing Database Connection: Lastly, the script sets up a connection to a database service, specifically to a certain collection within the Cosmos DB database. The script also checks if the connection to the database was successful by sending a “ping” – if it receives a response, it knows the connection is good.

from azure.identity import AzureCliCredential
from azure.keyvault.secrets import SecretClient
import openai
import logging
import tiktoken
import pandas as pd
import pymongo
from dotenv import load_dotenv
load_dotenv()
# Set up the Azure Key Vault client and retrieve the Blob Storage account credentials
keyvault_name = ''
openaiservicename = ''
client = SecretClient(f"https://{keyvault_name}.vault.azure.net/", AzureCliCredential())
print('keyvault service ready')
# AzureOpenAI Service
def setup_azureopenai():
    openai.api_key = client.get_secret('openai-api-key').value
    openai.api_type = "azure"
    openai.api_base = f'https://{openaiservicename}.openai.azure.com'
    openai.api_version = '2023-05-15'
    print('azure openai service ready')
# public openai service
def setup_public_openai():
    openai.api_key = client.get_secret('openai-api-key-public').value
    print('public openai service ready')
DB_NAME = "hephaestus"
COLLECTION_NAME = 'isocodes'
def setup_cosmos_connection():
    COSMOS_CLUSTER_CONNECTION_STRING = client.get_secret('cosmos-cluster-string').value
    cosmosclient = pymongo.MongoClient(COSMOS_CLUSTER_CONNECTION_STRING)
    db = cosmosclient[DB_NAME]
    collection = cosmosclient[DB_NAME][COLLECTION_NAME]
    # Send a ping to confirm a successful connection
    try:
        cosmosclient.admin.command('ping')
        print("Pinged your deployment. You successfully connected to MongoDB!")
    except Exception as e:
        print(e)
    return collection, db
setup_public_openai()
collection, db = setup_cosmos_connection()

Now we have set things up to interact with our Cosmos DB Mong DB vCore instance.

Step #2 Functions for Populating the Vector DB

Next, we prepare and insert data into the database as embeddings. First, we prepare the content. The preparation process involves turning the text content into embeddings. Each embedding is a list of flats representing the meaning of a specific part of the text in a way the AI system can understand.

We create the embeddings by sending text (for example, a paragraph of a document) to an OpenAI embedding model that returns the embedding. There are two options for using OpenAI: You can use the Azure OpenAI engine and deploy your own Ada embedding model. Alternatively, you can use the public OpenAI Ada embedding model.

We’ll use the public OpenAI’s text-embedding-ada-002. Remember that the model is designed to return embeddings, not text. Model inference may incur costs based on the data processed. Refer to OpenAI or Azure OpenAI service for pricing details.

Finally, the code inserts the prepared requests (which now include both the original text and the corresponding embeddings) into the database. The function returns the unique IDs assigned to these newly inserted items in the database. In this way, the code processes and stores the necessary information in the database for later use.

# prepare content for insertion into cosmos db
def prepare_content(text_content):
  embeddings = create_embeddings_with_openai(text_content)
  request = [
    {
    "textContent": text_content,
    "vectorContent": embeddings}
  ]
  return request
# create embeddings
def create_embeddings_with_openai(input):
    #print('Generating response from OpenAI...')
    ###### uncomment for AzureOpenAI model usage and comment code below
    # embeddings = openai.Embedding.create(
    #     engine='<name of the embedding deployment >',
    #     input=input)["data"][0]["embedding"]
    ###### public openai model usage and comment code above
    embeddings = openai.Embedding.create(
        model='text-embedding-ada-002',
        input=input)["data"][0]["embedding"]

    # Number of embeddings
    # print(len(embeddings))
    return embeddings
# insert the requests
def insert_requests(text_input):
    request = prepare_content(text_input)
    return collection.insert_many(request).inserted_ids
# Creates a searchable index for the vector content
def create_index():

  # delete and recreate the index. This might only be necessary once.
  collection.drop_indexes()
  embedding_len = 1536
  print(f'creating index with embedding length: {embedding_len}')
  db.command({
    'createIndexes': COLLECTION_NAME,
    'indexes': [
      {
        'name': 'vectorSearchIndex',
        'key': {
          "vectorContent": "cosmosSearch"
        },
        'cosmosSearchOptions': {
          'kind': 'vector-ivf',
          'numLists': 100,
          'similarity': 'COS',
          'dimensions': embedding_len
        }
      }
    ]
  })
# Resets the DB and deletes all values from the collection to avoid dublicates
#collection.delete_many({})

Step #3 Document Cracing and Populating the DB

The next step is to break down the PDF document into smaller chunks of text (in this case, ‘records’) and then process these records for future use. You can repeat this process for any document that you want to make available to OpenAI.

You can use any PDF that you like as long as you it contains readable text (use OCR). For demo purposes, I will use a tax document from Zurich. Put the document in the folder data/vector_db_data/ in your root folder and provide the name to the Python script.

Want to read in many documents at once? If you want to insert many documents, read the pdf documents from the folder and use the names to populate a list. You can then surround the insert function with a for loop that iterates through the list of document names

#3.1 Document Slicing Considerations

To convert a PDF into embeddings, the first step is to divide it into smaller content slices. The slicing process plays a crucial role as it affects the information provided to the OpenAI GPT model when answering user questions. If the slices are too large, the model may encounter token limitations. Conversely, if they are too small, the model may not receive sufficient content to answer the question effectively. It is important to strike a balance between the number of slices and their length to optimize the results, considering that the search process may yield multiple outcomes.

There are several approaches to handle the slicing process. One option is to define the slices based on a specific number of sentences or paragraphs. Alternatively, you can iteratively slice the document, allowing for some overlap between the data in the vector database. This approach has the advantage of providing more precise information to answer questions, but it also increases the data volume in the vector database, which can impact speed and cost considerations.

#3.2 Running the code below to crack a document and insert embeddings into the vector DB

Running the code below will first define a function that breaks text into separate paragraphs based on line breaks. Another function slices the PDF into records. Each record contains a certain number of sentences (the maximum is defined by the ‘max_sentences’ value). We use a Python library called PyPDF2 to extract text from each page of the PDF and Python’s built-in regular expressions to split the text into sentences and paragraphs. Note that if you want to achieve better results, you could also use a professional document content extraction tool such as Azure form recognizer.

The code then opens a specific PDF file (‘zurich_tax_info_2023.pdf’) and slices it into records, each containing no more than a certain number of sentences (as defined by’max_sentences’). After that, the function inserts these records into the vector database. Finally, we print the count of documents in the database collection. This shows how many pieces of data are already stored in this specific part of the database.

# document cracking function to insert data from the excel sheet
def split_text_into_paragraphs(text):
    paragraphs = re.split(r'\n{2,}', text)
    return paragraphs
def slice_pdf_into_records(pdf_path, max_sentences):
    records = []

    with open(pdf_path, 'rb') as file:
        reader = PyPDF2.PdfReader(file)

        for page in reader.pages:
            text = page.extract_text()
            paragraphs = split_text_into_paragraphs(text)

            current_record = ''
            sentence_count = 0

            for paragraph in paragraphs:
                sentences = re.split(r'(?<=[.!?])\s+', paragraph)

                for sentence in sentences:
                    current_record += sentence

                    sentence_count += 1

                    if sentence_count >= max_sentences:
                        records.append(current_record)
                        current_record = ''
                        sentence_count = 0

                if sentence_count < max_sentences:
                    current_record += ' '  # Add space between paragraphs

            # If there is remaining text after the loop, add it as a record
            if current_record:
                records.append(current_record)

    return records
# get file from root/data folder
pdf_path = '../data/vector_db_data/zurich_tax_info_2023.pdf'
max_sentences = 20  # Adjust the slice size as per your requirement
result = slice_pdf_into_records(pdf_path, max_sentences)
# print the length of result
print(f'{len(result)} vectors created with maximum {max_sentences} sentences each.')
# Print the sliced records
for i, record in enumerate(result):
    insert_requests(record)
    if i < 5:
        print(record[0:100])
        print('-------------------')
create_index()
print(f'number of records in the vector DB: {collection.count_documents({})}')

After slicing the document and inserting the embeddings into the vector database, we can proceed with functions for similarity search and prompting.

Step #4 Functions for Similarity Search and Prompts to ChatGPT

This section of code provides a set of functions to perform a vector search in the Cosmos DB, make a request to the ChatGPT 3.5 Turbo model for generating responses, and create prompts for the OpenAI model to use in generating those responses.

#4.1 How the Search Part Works

Allow me to provide a concise explanation of how the search process operates. We have now reached the stage where a user poses a question, and we utilize the OpenAI model to supply an answer, drawing from our vector database. Here, it’s vital to understand that the model transforms the question into embeddings and subsequently scours the knowledge base for similar embeddings that align with the information requested in the user’s prompt.

The vector database yields the most suitable results and inserts them into another prompt tailored for ChatGPT. This model, distinct from the embedding model, generates text. Thus, the final interaction with the ChatGPT model incorporates both the user’s question and the results from the vector database, which are the most fitting responses to the question. This combination should ideally aid the model in providing the appropriate answer. Now, let’s turn our attention to the corresponding code.

#4.2 Setting up the Functions for Vector Search

The vector_search function takes as input a query vector (representing a user’s question in vector form) and an optional parameter to limit the number of results. It then conducts a search in the Cosmos DB, looking for entries whose vector content is most similar to the query vector.

Next, the openai_request function makes a request to OpenAI’s ChatGPT 3.5 Turbo model to generate a response. This function takes a formatted conversation history (or ‘prompt’) and sends it to the model, which then generates a response. The content of the generated response is then returned.

The create_tweet_prompt function constructs the conversation history for the OpenAI model. This function takes the user’s question and a JSON object containing results from a database search and constructs a list of system and user messages. This list will then serve as the prompt for the ChatGPT model, instructing it to generate a response that answers the user’s question about tax, with the added guideline that the response should be in the same language as the question. The constructed prompt is then returned by the function.

# Cosmos DB Vector Search API Command
def vector_search(vector_query, max_number_of_results=2):
  results = collection.aggregate([
    {
      '$search': {
        "cosmosSearch": {
          "vector": vector_query,
          "path": "vectorContent",
          "k": max_number_of_results
        },
      "returnStoredSource": True
      }
    }
  ])
  return results
# openAI request - ChatGPT 3.5 Turbo Model
def openai_request(prompt, model_engine='gpt-3.5-turbo'):
    completion = openai.ChatCompletion.create(model=model_engine, messages=prompt, temperature=0.2, max_tokens=500)
    return completion.choices[0].message.content
# define OpenAI Prompt for News Tweet
def create_prompt(user_question, result_json):
    instructions = f'You are an assistant that answers questions based on sources provided. \
    If the information is not in the provided source, you answer with "I don\'t know". '
    task = f"{user_question} Translate the response to english /n \
    source: {result_json}"

    prompt = [{"role": "system", "content": instructions },
              {"role": "user", "content": task }]
    return prompt

You can easily change the voice and tone in which the ChatGPT answers questions by including the respective instructions in the create_prompt function.

Also: ChatGPT Style Guide: Understanding Voice and Tone Prompt Options for Engaging Conversations

Step #5 Testing the Custom ChatGPT Solution

This part of the code works with the previous functions to facilitate a complete question-answering cycle with Cosmos DB and OpenAI’s ChatGPT 3.5 Turbo model.

Now comes the most exciting part. Testing the solution, you can define a question and then execute the code below to run the search process.

# define OpenAI Prompt
users_question = "When do I have to submit my tax return?"
# generate embeddings for the question
user_question_embeddings = create_embeddings_with_openai(user_question)
# search for the question in the cosmos db
search_results = vector_search(user_question_embeddings, 1)
print(search_results)
# prepare the results for the openai prompt
result_json = []
# print each document in the result
# remove all empty values from the results json
search_results = [x for x in search_results if x]
for doc in search_results:
    display(doc.get('_id'), doc.get('textContent'), doc.get('vectorContent')[0:5])
    result_json.append(doc.get('textContent'))
# create the prompt
prompt = create_prompt(user_question, result_json)
display(prompt)
# generate the response
response = openai_request(prompt)
display(f'User question: {users_question}')
display(f'OpenAI response: {response}')

‘User question: When do I have to submit my tax return?’

'OpenAI response: When do I have to submit my tax return? \n\nAll natural persons who had their residence in the canton of Zurich on December 31, 2022, or who owned properties or business premises (or business operations) in the canton of Zurich, must submit a tax return for 2022 in the calendar year 2023. Taxpayers with a residence in another canton also have to submit a tax return for 2022 in the calendar year 2023 if they ended their tax liability in the canton of Zurich by giving up a property or business premises during the calendar year 2022. If you turned 18 in the tax period 2022 (persons born in 2004), you must submit your own tax return (for the tax period 2022) for the first time in the calendar year 2023.'

As of Mai 2023, the knowledge base of ChatGPT 3.5 is limited to the timeframe before September 2021. So it’s evident that the response of our custom ChatGPT solution is based on the individual information provided in the vector database. Remember that we did not fine-tune the GPT model, so the model itself does not inherently know anything about your private data and instead uses the data that was dynamically provided to it as part of the prompt.

Real-world Applications of Chat with your data

Summary

In this comprehensive guide, we’ve journeyed through the fascinating process of creating a customized ChatGPT that lets users chat with your business data. We started with understanding the immense value a tailored ChatGPT brings to the table and dove into its ability to produce specialized responses sourced from a custom knowledge base. This tailored approach enhances user experiences, saves time, and bolsters productivity.

We went behind the scenes to reveal the vital elements of crafting a custom ChatGPT: OpenAI’s GPT models, data embeddings, and vector databases like Cosmos DB for Mongo DB vCore. We clarified how these components synergize to transcend the token limitations inherent to GPT models. By integrating the components in Python, we broadened ChatGPT’s ability to answer queries based on your private knowledgebase, thereby offering contextually appropriate responses.

I hope this tutorial was able to illustrate the business value of ChatGPT and its versatile utility across a variety of sectors, including customer service, healthcare, legal services, finance, e-learning, and CRM data analytics. Each instance emphasized the transformative potential of a personalized ChatGPT in delivering efficient, targeted solutions.

I hope you found this helpful article. If you have any questions or remarks, please drop them in the comment section.

Sources and Further Reading

• Azure Cosmos DB
• OpenAI pricing
• Azure OpenAI
• Semantic search
• What are embeddings?
• Using vector search on embeddings in Azure Cosmos DB for MongoDB vCore
• OpenAI ChatGPT helped to revise this article
• Images created with Midjourney

The post Building “Chat with your Data” Apps using Embeddings, ChatGPT, and Cosmos DB for Mongo DB vCore appeared first on relataly.com.

What is Hierarchical Clustering?

Agglomerative Clustering

In this article, we will apply the agglomerative clustering approach, which is a bottom-up approach to clustering. The idea is to initially treat each data point in a dataset as its own cluster and then combine the points with other clusters as the algorithm progresses. The process of agglomerative clustering can be broken down into the following steps:

1. Start with each data point in its own cluster.
2. Calculate the similarity between all pairs of clusters.
3. Merge the two most similar clusters.
4. Repeat steps 2 and 3 until all the data points are in a single cluster or until a predetermined number of clusters is reached.

There are several ways to calculate the similarity between clusters, including using measures such as the Euclidean distance, cosine similarity, or the Jaccard index. The specific measure used can impact the results of the clustering algorithm.

For details on how the clustering approach works, see the Wikipedia page.

Hierarchical Clustering vs. K-means

Customer Segmentation using Hierarchical Clustering in Python

In this comprehensive guide, we explore the application of hierarchical clustering for effective customer segmentation using a customer dataset. This data-driven segmentation method enables businesses to identify distinct customer clusters based on various factors, including demographics, behaviors, and preferences.

Customer segmentation is a strategic approach that splits a customer base into smaller, more manageable groups with similar characteristics. It aims to better understand the diverse needs and wants of different customer segments to enhance marketing strategies and product development.

Applying customer segmentation through hierarchical clustering allows businesses to personalize their marketing messages, design targeted campaigns, and tailor products to meet the unique needs of each segment. This proactive approach can stimulate increased customer loyalty and sales.

We begin by loading the customer data and selecting the relevant features we want to use for clustering. We then standardize the data using the StandardScaler from scikit-learn. Next, we apply hierarchical clustering using the AgglomerativeClustering method, specifying the number of clusters we want to create. Finally, we add the predictions to the original data as a new column and view the resulting segments by calculating the mean of each feature for each segment.

The code is available on the GitHub repository.

View on GitHub Relataly GitHub Repo

About the Customer Health Insurance Dataset

Prerequisites

Before we start the coding part, ensure that you have set up your Python 3 environment and the required packages. If you don’t have an environment, follow this tutorial to set up the Anaconda environment. Also, make sure you install all required packages. In this tutorial, we will be working with the following standard packages:

• pandas
• NumPy
• matplotlib
• scikit-learn

You can install packages using console commands:

pip install <package name>
conda install <package name> (if you are using the anaconda packet manager)

Step #1 Load the Data

To begin, we need to load the required packages and the data we want to cluster. We will load the data by reading the CSV file via the pandas library.

# import necessary libraries
import matplotlib.pyplot as plt
from sklearn.preprocessing import StandardScaler
from sklearn.cluster import AgglomerativeClustering
from sklearn.preprocessing import LabelEncoder
from pandas.api.types import is_string_dtype
import pandas as pd
import math
import seaborn as sns

# load customer data
customer_df = pd.read_csv("data/customer/customer_health_insurance.csv")
customer_df.head(3)

	age	sex		bmi		children	smoker	region		charges
0	19	female	27.90	0			yes		southwest	16884.9240
1	18	male	33.77	1			no		southeast	1725.5523
2	28	male	33.00	3			no		southeast	4449.4620

Step #2 Explore the Data

Next, it is a good idea to explore the data and get a sense of its structure and content. This can be done using a variety of methods, such as examining the shape of the dataframe, checking for missing values, and plotting some basic statistics. For example, the following plots will explore the relationships between some of the variables. We won’t go into too much detail here.

def make_kdeplot(df, column_name, target_name):
    fig, ax = plt.subplots(figsize=(10, 6))
    sns.kdeplot(data=df, hue=column_name, x=target_name, ax = ax, linewidth=2,)
    ax.tick_params(axis="x", rotation=90, labelsize=10, length=0)
    ax.set_title(column_name)
    ax.set_xlim(0, df[target_name].quantile(0.99))
    plt.show()

# make kde plot for ext_color
make_kdeplot(customer_df, 'smoker', 'charges')

# make kde plot for ext_color
make_kdeplot(customer_df, 'sex', 'charges')

sns.lmplot(x="charges", y="age", hue="smoker", data=customer_df, aspect=2)
plt.show()

def make_boxplot(customer_df, x,y,h):
    fig, ax = plt.subplots(figsize=(10,4))
    box = sns.boxplot(x=x, y=y, hue=h, data=customer_df)
    box.set_xticklabels(box.get_xticklabels())
    fig.subplots_adjust(bottom=0.2)
    plt.tight_layout()

make_boxplot(customer_df, "smoker", "charges", "sex")

make_boxplot(customer_df, "region", "charges", "sex")

make_boxplot(customer_df, "children", "bmi", "sex")

Next, let’s prepare the data for model training.

Step #3 Prepare the Data

Before we can train a model on the data, we must prepare it for modeling. This typically involves selecting the relevant features, handling missing values, and scaling the data. However, we are using a very simple dataset that already has good data quality. Therefore we can limit our data preparation activities to encoding the labels and scaling the data.

To encode the categorical values, we will use label encoder from the scikit-learn library.

# encode categorical features
label_encoder = LabelEncoder()

for col_name in customer_df.columns:
    if (is_string_dtype(customer_df[col_name])):
        customer_df[col_name] = label_encoder.fit_transform(customer_df[col_name])
customer_df.head(3)

Next, we will scale the numeric variables. While scaling the data is an essential preprocessing step for many machine learning algorithms to work effectively, it is generally not necessary for hierarchical clustering. This is because hierarchical clustering is not sensitive to the scale of the features. However, when you use certain distance measures, such as Euclidean distance, scaling the data might still be useful when performing hierarchical clustering. Scaling the data can help to ensure that all of the features are given equal weight. This can be useful if you want to avoid giving more weight to features with larger scales.

# select features
X = customer_df # we will select all features

# standardize the data
scaler = StandardScaler()
X_scaled = scaler.fit_transform(X)
X_scaled.head(3)

array([[-1.43876426, -1.0105187 , -0.45332   , ...,  1.34390459,
         0.2985838 ,  1.97058663],
       [-1.50996545,  0.98959079,  0.5096211 , ...,  0.43849455,
        -0.95368917, -0.5074631 ],
       [-0.79795355,  0.98959079,  0.38330685, ...,  0.43849455,
        -0.72867467, -0.5074631 ],
       ...,
       [-1.50996545, -1.0105187 ,  1.0148781 , ...,  0.43849455,
        -0.96159623, -0.5074631 ],
       [-1.29636188, -1.0105187 , -0.79781341, ...,  1.34390459,
        -0.93036151, -0.5074631 ],
       [ 1.55168573, -1.0105187 , -0.26138796, ..., -0.46691549,
         1.31105347,  1.97058663]])

Step #4 Train the Hierarchical Clustering Algorithm

To train a hierarchical clustering model using scikit-learn, we can use the AgglomerativeClustering or Ward class. The main parameters for these classes are:

• n_clusters: The number of clusters to form. This parameter is required for AgglomerativeClustering but is not used for Ward.
• affinity: The distance measure used to calculate the similarity between pairs of samples. This can be any of the distance measures implemented in scikit-learn, such as the Euclidean distance or the cosine similarity.
• linkage: The method used to calculate the distance between clusters. This can be one of “ward,” “complete,” “average,” or “single.”
• distance_threshold: The maximum distance between two clusters that allows them to be merged. This parameter is only used in the AgglomerativeClustering class.

To train the model, we specify the desired parameters and fit the model to the data using the fit_predict method. This method will fit the model to the data and generate predictions in one step.

# apply hierarchical clustering
model = AgglomerativeClustering(affinity='euclidean')
predicted_segments = model.fit_predict(X_scaled)

Now we have a trained clustering model also predicted the segments for our data.

Step #5 Visualize the Results

After the model is trained, we can visualize the results to get a better understanding of the clusters that were formed. There is a wide range of plots and tools to visualize clusters. In this tutorial, we will use a scatterplot and a dendrogram.

5.1 Scatterplot

For this, we can use the lmplot function in Seaborn. The lmplot creates a 2D scatterplot with an optional overlay of a linear regression model. The plot visualizes the relationship between two variables and fits a linear regression model to the data that can highlight differences. In the following, we use this linear regression model to highlight the differences between our two cluster segments and the age of the customers.

# add predictions to data as a new column
customer_df['segment'] = predicted_segments

# create a scatter plot of the first two features, colored by segment
sns.lmplot(x="charges", y="age", hue="segment", data=customer_df, aspect=2)
plt.show()

We can see that our model has determined two clusters in our data. The clusters seem to correspond well with the smoker category, which indicates that this attribute is decisive in forming relevant groups.

5.2 Dendrogram

The hierarchical clustering approach lets us visualize relationships between different groups in our dataset in a dendrogram. A dendrogram is a graphical representation of a hierarchical structure, such as the relationships between different groups of objects or organisms. It is typically used in biology to show the relationships between different species or taxonomic groups, but it can also be used in other fields to represent the hierarchical structure of any set of data. In a dendrogram, the objects or groups being studied are represented as branches on a tree-like diagram. The branches are usually labeled with the names of the objects or groups, and the lengths of the branches represent the distances or dissimilarities between the objects or groups. The branches are also arranged in a hierarchical manner, with the most closely related objects or groups being placed closer together and the more distantly related ones being placed farther apart.

# Visualize data similarity in a dendogram
def plot_dendrogram(model, **kwargs):
    # create the counts of samples under each node
    counts = np.zeros(model.children_.shape[0])
    n_samples = len(model.labels_)
    for i, merge in enumerate(model.children_):
        current_count = 0
        for child_idx in merge:
            if child_idx < n_samples:
                current_count += 1  # leaf node
            else:
                current_count += counts[child_idx - n_samples]
        counts[i] = current_count

    linkage_matrix = np.column_stack(
        [model.children_, model.distances_, counts]
    ).astype(float)

    # Plot the corresponding dendrogram
    dendrogram(linkage_matrix, orientation='right',**kwargs)


plt.title("Hierarchical Clustering Dendrogram")
# plot the top three levels of the dendrogram
plot_dendrogram(cluster_model, truncate_mode="level", p=4)
plt.xlabel("Euclidean Distance")
plt.ylabel("Number of points in node (or index of point if no parenthesis).")
plt.show()

Source: This code block is based on code from the scikit-learn page

Summary

In conclusion, hierarchical clustering is a powerful tool for customer segmentation that can help businesses better understand their customer base and target their marketing efforts more effectively. By grouping customers into clusters based on their characteristics and behaviors, companies can create targeted campaigns and personalize their marketing efforts to better meet the needs of each group. Using Python and the scikit-learn library, we were able to apply an agglomerative clustering approach to a dataset of customer data and identify two distinct segments. We can then use these segments to inform our marketing strategies and get a better understanding of our customers.

By the way, customer segmentation is an area where real-world data can be prone to bias and unfairness. If you’re concerned about this, check out our latest article on addressing fairness in machine learning with fairlearn.

I hope this article was useful. If you have any feedback, please write your thoughts in the comments.

Sources and Further Reading

Articles

• https://scikit-learn.org/stable/auto_examples/cluster/plot_agglomerative_dendrogram.html
• Images generated with OpenAI Dall-E and Midjourney.

The links above to Amazon are affiliate links. By buying through these links, you support the Relataly.com blog and help to cover the hosting costs. Using the links does not affect the price.

Relataly articles on clustering and machine learning

• Simple Clustering using K-means in Python: This article gives an overview of cluster analysis with k-means.
• Clustering crypto markets using affinity propagation in Python: This article applies cluster analysis to crypto markets and creates a market map for various cryptocurrencies.
• Addressing fairness in machine learning with the fairlearn library

The post How to Use Hierarchical Clustering For Customer Segmentation in Python appeared first on relataly.com.

What is Stock Market Clustering?

Clustering stock markets refers to grouping stocks based on their similarities or common characteristics. This can be done using various clustering algorithms, which analyze the data and assign each stock market to a cluster based on its similarity to other stock markets in the same cluster. In this article, we will run a cluster analysis on historical time series data. This approach involves grouping stocks into clusters based on their historical performance over a certain period of time.

Clustering stock market data can be useful for a variety of purposes, such as identifying patterns or trends in the data, comparing the performance of different stocks or sectors, or generating investment recommendations. However, it’s important to keep in mind that clustering is just one tool among many for analyzing stock market data, and it’s important to consider a range of factors when making investment decisions. It can also be used to compare the performance of different stock markets and identify potential risks or correlations between them.

Also: Color-Coded Cryptocurrency Price Charts in Python

What’s the Problem with Prototype-based Clustering?

Affinity Propagation: What it is and How it Works

The idea of affinity propagation is to identify clusters by measuring the similarity of data points relative to one another. The algorithm chooses data points as cluster centers that best represent other data points near them.

We can imagine the process of identifying these representative data points as an election. Each data point (i) is a voter who casts votes and a candidate (k) who can receive votes from other voters. Votes are a measure of the similarity of data points. A voter who gives many votes to a candidate expresses that this data point is similar to him and therefore is suitable for representing him as a cluster center. The voting process continues until the algorithm reaches a consensus and selects a set number of cluster candidates.

The clustering process involves many separate steps (This article provides a detailed description of the steps involved) and works with several matrices:

• The similarity matrix assesses the suitability of data points (candidates) to act as cluster centers.
• The availability matrix (or responsibility matrix) collects the support of the data points for the candidates (potential cluster centers) and their suitability to represent them.
• The criterion matrix sums up the results and defines the clusters. Data points with equal scores in the criterion matrix are considered part of the same cluster.

Time Series Clustering using Affinity Propagation – Visualizing Cryptocurrency Market Structures in Python

Ready to implement affinity propagation in Python to analyze the crypto market structure and create a visual representation of price similarity? Let’s dive in!

First, we define a portfolio of cryptocurrencies and download their historical price quotes from coinmarketcap. We then visualize the time series on separate line charts to ensure that the data has been loaded successfully. After preparing and cleaning the data, we can move on to clustering the cryptocurrencies into groups with similar price movements using Affinity Propagation.

Unlike other clustering algorithms, we don’t set the number of clusters in advance. Instead, we let affinity propagation determine the optimal number of clusters for our portfolio. Finally, we calculate the covariance matrix between clusters and arrange the cryptocurrencies on a 2D map into clusters. We create a network overlay based on covariance to better understand the relationships between different clusters.

With affinity propagation, we can identify hidden patterns in the crypto market and group coins into clusters based on their past price fluctuations. This process allows us to identify promising entry and exit points, ultimately helping us make smarter investment decisions. Plus, the 2D map and network overlay help us visualize the relationships between different clusters and coins.

Prerequisites

Step #1: Load the Stock Market Data

We start by loading historical crypto price data from Coinmarketcap. To download the data, we use Cmcscraper, a Python library that allows us to collect Coinmarketcap data without signing up for the official API.

The download returns a dataframe with daily price quotes (Close, Open, Avg) for cryptocurrencies between 2016 and today. You can use the dictionary (“symbol_dict”) to control which cryptos you want to include in the data. We limit the data we use in our cluster analysis to the last 50 days. In this way, we let the correlation consider earlier price developments. But it’s up to you to specify a different period. In addition, instead of using absolute price values, we will use daily percentage fluctuations.

Also: Requesting Crypto Price Data from the Gate.io REST API in Python

Loading the data can take several minutes, depending on how many cryptocurrencies we include in the request. So it makes sense not to load the data every time you run the code. Therefore, the code below stores the historical prices in a CSV file.

The script will check if the data already exists if you run the code below. If it does, it will use the data from the CSV file. Otherwise, it will load a fresh copy of the data from coinmarketcap.

# A tutorial for this file is available at www.relataly.com
# Tested with Python 3.8.8, Matplotlib 3.5, Scikit-learn 0.24.1, Seaborn 0.11.1, numpy 1.19.5

from cryptocmd import CmcScraper
import pandas as pd
import matplotlib.pyplot as plt
import numpy as np
import seaborn as sns
from sklearn import cluster, covariance, manifold
import requests
import json


#get a dictionary of the top 100 coin symbols and names from an API
def get_symbol_dict():
    url = 'https://api.coinmarketcap.com/data-api/v3/cryptocurrency/listing?start=1&limit=50&sortBy=market_cap&sortType=desc&convert=USD&cryptoType=all&tagType=all&audited=false'
    response = requests.get(url)
    data = json.loads(response.text)
    df = pd.DataFrame(data['data']['cryptoCurrencyList'])

    # exclude stable coins
    df = df[~df['symbol'].isin(['USDT', 'USDC', 'BUSD', 'DAI', 'TUSD', 'PAX', 'GUSD', 'HUSD', 'USDK', 'USDS', 'USDP', 'USDN', 'USDSB', 'USDX', 'USD++', 'BIDR', 'IDRT', 'VAI', 'BGBP'])]
    df = df[['symbol', 'name']]
    df = df.set_index('symbol')
    df = df.to_dict()
    df = df['name']
    return df

symbol_dict = get_symbol_dict()


# Download historic crypto prices via CmcScraper
def load_fresh_data_and_save_to_disc(symbol_dict, save_path):
    # Extract symbols and names from the symbol_dict
    symbols, names = np.array(sorted(symbol_dict.items())).T

    # Initialize an empty DataFrame for storing the prices
    df_crypto = pd.DataFrame()

    # Download and process the price data for each symbol
    for symbol in symbols:
        print(f"Fetching prices for {symbol}...")

        # Download the price data using CmcScraper
        scraper = CmcScraper(symbol)
        df_coin_prices = scraper.get_dataframe()

        # Process the price data and add it to df_crypto
        df = pd.DataFrame({
            f"{symbol}_Open": df_coin_prices["Open"],
            f"{symbol}_Close": df_coin_prices["Close"],
            f"{symbol}_Avg": (df_coin_prices["Close"] + df_coin_prices["Open"]) / 2,
            f"{symbol}_p": (df_coin_prices["Open"] - df_coin_prices["Close"]) / df_coin_prices["Open"]
        })
        df_crypto = pd.concat([df_crypto, df], axis=1)

    # Save the price data to a CSV file
    X_df_filtered = df_crypto.filter(like="_p")
    X_df_filtered.to_csv(save_path + "historical_crypto_prices.csv")

    return names, symbols, X_df_filtered


# If set to False the data will only be downloaded when you execute the code
# Set to True, if you want a fresh copy of the data.
fetch_new_data = True
save_path = '' # path where the price data will be stored in a csv file

# Fetch fresh data via the scraping package, or use data from the csv file on disk
if fetch_new_data == False:
    try:
        print('loading from disk')
        X_df_filtered = pd.read_csv(save_path + 'historical_crypto_prices.csv')
        if 'Unnamed: 0' in X_df_filtered.columns:
            X_df_filtered = X_df_filtered.drop(['Unnamed: 0'], axis=1)
            symbols, names = np.array(sorted(symbol_dict.items())).T
        print(list(X_df_filtered.columns))
    except:
        print('no existing price data found - loading fresh data from coinmarketcap and saving them to disk')
        names, symbols, X_df_filtered = load_fresh_data_and_save_to_disc(symbol_dict, save_path)
        print(list(symbols))
else:
       print('loading fresh data from coinmarketcap and saving them to disk')
       names, symbols, X_df_filtered = load_fresh_data_and_save_to_disc(symbol_dict, save_path)
       print(list(symbols))

# Limit the price data to the last t days
t= 14 # in days
X_df_filtered = X_df_filtered[:t]
X_df_filtered.head()

	ACM_p		ADA_p		ARK_p		ATM_p		ATOM_p		AVAX_p		BAT_p		BCH_p		BLZ_p		BNB_p		...	THETA_p		UNI_p		USDT_p		VET_p		WAVES_p		XLM_p		XMR_p		XRP_p		ZIL_p		ZRX_p
0	0.031987	-0.037645	-0.005702	0.030928	-0.005897	-0.012404	-0.012262	-0.022529	0.008072	-0.007111	...	-0.021994	-0.023758	-0.000103	-0.021024	-0.015416	-0.004096	-0.022988	-0.027397	-0.016659	-0.012255
1	0.028192	0.065034	0.122306	0.010310	0.093558	0.106811	0.082863	0.075567	0.062105	0.054733	...	0.067264	0.081040	0.000136	0.077203	0.092987	0.078562	0.111519	0.071696	0.076484	0.085094
2	0.040771	0.016097	-0.133345	0.018963	0.011304	-0.033328	-0.007616	0.011458	-0.019993	0.005134	...	-0.005104	-0.024190	0.000077	0.002218	0.008920	0.004139	-0.031822	-0.012107	-0.003906	-0.021170
3	-0.027698	0.005129	-0.031516	-0.002639	0.022235	-0.008117	0.003969	0.019119	0.015403	0.005920	...	0.007992	0.027203	0.000003	0.000701	0.010739	0.005324	-0.007914	0.007168	0.004556	-0.003786
4	-0.021129	-0.019053	0.003273	-0.008121	0.002883	-0.004927	0.002548	-0.000599	0.028492	-0.012181	...	0.000198	-0.025817	-0.000047	-0.002800	-0.051515	-0.004861	0.015134	-0.000596	-0.010343	0.004530

The data looks good, so let’s continue.

Step #2 Plotting Crypto Price Charts

Now that the data is available, we can visualize it in various line graphs. The visualization helps us better understand what kind of data we are dealing with and check if the download was successful.

# Create Prices Charts for all Cryptocurrencies
list_length = X_df_filtered.shape[1]
ncols = 10
nrows = int(round(list_length / ncols, 0))
height = list_length/3 if list_length > 30 else 4
fig, axs = plt.subplots(nrows=nrows, ncols=ncols, sharex=True, sharey=True, figsize=(20, height))
for i, ax in enumerate(fig.axes):
        if i < list_length:
            sns.lineplot(data=X_df_filtered, x=X_df_filtered.index, y=X_df_filtered.iloc[:, i], ax=ax)
            ax.set_title(X_df_filtered.columns[i])
plt.show()

We can see the lineplots for all cryptocurrencies and everything looks as expected.

Step #3 Clustering Cryptocurrencies using Affinity Propagation

Next, we must prepare the data and run the affinity propagation algorithm. For some cryptocurrencies, we may encounter data that contains NaN values. Because clustering is sensitive to missing values, we must ensure good data quality. In addition, the Python code below will convert the DataFrame into a NumPy array and transpose it into a form where we have crypto assets as records and the days as columns.

Running the code below returns a dictionary of clusters with the cryptocurrencies assigned to them by the affinity propagation algorithm.

# Drop NaN values
X_df = pd.DataFrame(np.array(X_df_filtered)).dropna()
# Transpose the data to structure prices along columns
X = X_df.copy()
X /= X.std(axis=0)
X = np.array(X)
# Define an edge model based on covariance
edge_model = covariance.GraphicalLassoCV()
# Standardize the time series
edge_model.fit(X)
# Group cryptos to clusters using affinity propagation
# The number of clusters will be determined by the algorithm
cluster_centers_indices , labels = cluster.affinity_propagation(edge_model.covariance_, random_state=1)
cluster_dict = {}
n_labels = labels.max()
print(f"{n_labels} Clusters")
for i in range(n_labels + 1):
    clusters = ', '.join(names[labels == i])
    print('Cluster %i: %s' % ((i + 1), clusters))
    cluster_dict[i] = (clusters)

9 Clusters
Cluster 1: Binance Coin, Cake Defi
Cluster 2: Bitcoin Cash, Bitcoin, BitTorrent, Decred, EOS, Ethereum Classic, Ethereum, Ampleforth, Komodo, Solana, Sys Coin, DOT
Cluster 3: Celsius
Cluster 4: Doge Coin
Cluster 5: Cardano, ATOM, Avalance, Enjin, Internet Computer, Link, Loopring, Polygon, IOTA, NEO, Synthetix, Theta, Vechain
Cluster 6: Litecoin
Cluster 7: ACM Token, Atletico Madrid Token, Chilliz, Juventus Turin Token, PSG Token
Cluster 8: LRC
Cluster 9: Tether
Cluster 10: ARK, Battoken, BLZ, Digibyte, AS Rom Token, WAVES, Stellar Lumen, Monero, Ripple, Zilliqa, Zer0

We can see that the algorithm has identified 13 different clusters in the data and a couple of clusters with only a single member. You will most likely encounter different results depending on when you run it.

Step #4 Create a 2D Positioning Model based on the Graph Structure

In addition to clusters, we want to show the covariance between cryptocurrencies in our Crypto Market map. We need a graph-like structure that contains the covariance and position data of the cryptocurrencies for each crypto pair.

In addition, we use a node position model that calculates their relative position on a 2D plane from the covariance of the cryptocurrencies. However, the positions are only relative, so the absolute axes have no meaning.

# Create a node_position_model that find the best position of the cryptos on a 2D plane
# The number of components defines the dimensions in which the nodes will be positioned
node_position_model = manifold.LocallyLinearEmbedding(n_components=2, eigen_solver='dense', n_neighbors=20)
embedding = node_position_model.fit_transform(X.T).T
# The result are x and y coordindates for all cryptocurrencies
pd.DataFrame(embedding)
# Create an edge_model that represents the partial correlations between the nodes
partial_correlations = edge_model.precision_.copy()
d = 1 / np.sqrt(np.diag(partial_correlations))
partial_correlations *= d
partial_correlations *= d[:, np.newaxis]
# Only consider partial correlations above a specific threshold (0.02)
non_zero = (np.abs(np.triu(partial_correlations, k=1)) > 0.02)
# Convert the Positioning Model into a DataFrame
data = pd.DataFrame.from_dict({"embedding_x":embedding[0],"embedding_y":embedding[1]})
# Add the labels to the 2D positioning model
data["labels"] = labels
print(data.shape)
data.head()

(48, 3)
	embedding_x	embedding_y	labels
0	0.400590	-0.136473	6
1	-0.081908	-0.086039	4
2	-0.033982	-0.038526	9
3	0.416745	0.076849	6
4	-0.041938	0.031966	4

The next step is to create a graph of the partial correlations.

Step #5 Visualize the Crypto Market Structure

Our goal is to visualize differences in the covariance between crypto pairs by varying the connection strengths. We calculate the line strength by normalizing the covariance of the crypto pairs. In addition, we visualize the distribution of the covariance.

# Create an array with the segments for connecting the data points
start_idx, end_idx = np.where(non_zero)
segments = [[np.array([embedding[:, start], embedding[:, stop]]).T, start, stop] for start, stop in zip(start_idx, end_idx)]
# Create a normalized representation of partial correlation between crypto currencies
# We can later use covariance to vizualize the strength of the connections
pc = np.abs(partial_correlations[non_zero])
normalized = (pc-min(pc))/(max(pc)-min(pc))
# plot the distribution of covariance between the cryptocurrencies
sns.histplot(pc)

The hist plot shows that the covariance between the crypto pairs is mostly below 0.005.

Finally, it is time to map cryptocurrencies on a 2D plane. To do this, we first define the cryptocurrencies using their relative position data with a scatterplot. We set the color of the points based on their clusters so that points in the same cluster are colored the same. Subsequently, we connect the points to the data from the edge model. The covariance between the crypto pairs determines the strength of their connections.

We also define the color of the connections as follows.

• The map only shows connections with a covariance greater than 0.002.
• Connections with a covariance greater than 0.05 are colored red.
• Otherwise, connections between points within a cluster are shown in the cluster’s color.
• We color connections in grey that are between points of different clusters.

Last but not least, we add the labels of the cryptocurrencies.

# Visualization
plt.figure(1, facecolor='w', figsize=(20, 8))
plt.clf()
ax = plt.axes([0., 0., 1., 1.])

# Plot the nodes using the coordinates of our embedding
sc = sns.scatterplot(
    data=data,
    x="embedding_x",
    y="embedding_y",
    zorder=1,
    s=350 * d ** 2,
    c=labels,
    cmap=plt.cm.nipy_spectral,
    alpha=.9,
    #palette="muted",
)

# Plot the covariance edges between the nodes (scatter points)
line_strength = 3.2

for index, ((x, y), start, stop) in enumerate(segments):
    norm_partial_correlation = normalized[index]
    if list(data.iloc[[start]]['labels'])[0] == list(data.iloc[[stop]]['labels'])[0]:
        if norm_partial_correlation > 0.5:
            color = 'red'; linestyle='solid'
        else:
            color = plt.cm.nipy_spectral(list(data.iloc[[start]]['labels'])[0] / float(n_labels)); linestyle='solid'
    else:
        if norm_partial_correlation > 0.5:
            color = 'red'; linestyle='solid'
        else:
            color = 'grey'; linestyle='dashed'
    # Plot the edges
    # if x and y larger than 0
    if x[0] > 0 and y[0] > 0:
        plt.plot(x, y, alpha=.4, zorder=0, linewidth=normalized[index]*line_strength, color=color, linestyle=linestyle)


# Labels the nodes and position the labels to avoid overlap with other labels
for name, label, (x, y) in zip(names, labels, embedding.T):
    color = plt.cm.nipy_spectral(label / float(n_labels))
    ax.annotate(
        name,
        xy=(x, y),
        xytext=(5, 2),
        textcoords='offset points',
        ha='right',
        va='bottom',
        fontsize=10,
        color='black',
        bbox=dict(facecolor='w', edgecolor="w", alpha=.0),
     )

Note that you will likely see a different map when you run the code on your machine. Differences result from changes in market prices and covariance that lead to other graph structures.

Let’s see what the crypto market map tells us.

Interpreting the Cryptomarket Map

The 2D crypto market map tells us several things:

• Most cryptos fall into the light green and dark green clusters corresponding to different types of crypto (Decentralized Finance Coins, NFT/Metaverse Coins).
• There is a significant covariance between large-cap players in the crypto space, such as Cardano and Loopring and Ethereum and Bitcoin, which is plausible considering recent price movements. Some results are surprising, for example, the partial correlation between NEO and Ethereum Classic.
• Some clusters are isolated and contain only a single member, for example, Tether, Komodo, AC Milan token, Wave token, and Dogecoin). The reason is that the prices of these coins/tokens have developed independently of the market.
  • Tether is a stablecoin that does not change in price. It, therefore, strongly differs from the other cryptocurrencies on our map.
  • Komodo has been trading sideways without following the general market trend.
  • And the MCM token is a soccer token that has recently outperformed the market.
• Soccer tokens are colored in dark blue. These tokens’ prices correlate with how the soccer clubs performed during the current season. It, therefore, makes perfect sense that these tokens are grouped into a cluster. An exception is the AC Milan token, which recently performed better than the other soccer tokens.

Step #6 Creating a 3D Representation

Instead of a 2D representation of the data points, we can also use a 3D node positioning model. For this purpose, the node positioning model distributes the affinity values over three dimensions.

# Find the best position of the cryptos on a 3D plane
node_position_model = manifold.LocallyLinearEmbedding(n_components=3, eigen_solver='dense', n_neighbors=20)
embedding = node_position_model.fit_transform(X.T).T
# The result are x and y coordindates for all cryptocurrencies
pd.DataFrame(embedding)
# Display a graph of the partial correlations
partial_correlations = edge_model.precision_.copy()
d = 1 / np.sqrt(np.diag(partial_correlations))
partial_correlations *= d
partial_correlations *= d[:, np.newaxis]
non_zero = (np.abs(np.triu(partial_correlations, k=1)) > 0.02)
data = pd.DataFrame.from_dict({"embedding_x":embedding[0],"embedding_y":embedding[1],"embedding_z":embedding[1]})
data["labels"] = labels
data["names"] = names
import matplotlib.pyplot as plt
import numpy as np
fig = plt.figure(figsize=(20,20))
ax = fig.add_subplot(projection='3d')
xs = data["embedding_x"]
ys = data["embedding_y"]
zs = data["embedding_z"]
sc = ax.scatter(xs, ys, zs, c=labels, s=100)

for i in range(len(data)):
    x = xs[i]
    y = ys[i]
    z = zs[i]
    label = data["names"][i]
    ax.text(x, y, z, label)

plt.legend(*sc.legend_elements(), bbox_to_anchor=(1.05, 1), loc=2)
plt.show()

Summary

Sources and Further Reading

This article modifies some of the code from Scikit-learn and adapts it from the stock market to cryptocurrencies.

1. Jansen (2020) Machine Learning for Algorithmic Trading: Predictive models to extract signals from market and alternative data for systematic trading strategies with Python
2. Aurélien Géron (2019) Hands-On Machine Learning with Scikit-Learn, Keras, and TensorFlow: Concepts, Tools, and Techniques to Build Intelligent Systems
3. David Forsyth (2019) Applied Machine Learning Springer
4. Andriy Burkov (2020) Machine Learning Engineering
5. Images are created using Midjourney, an AI that creates images from text.

The links above to Amazon are affiliate links. By buying through these links, you support the Relataly.com blog and help to cover the hosting costs. Using the links does not affect the price.

The post Unveiling Hidden Patterns in the Cryptocurrency Market with Affinity Propagation and Python appeared first on relataly.com.

Embark on a journey into the world of unsupervised machine learning with this beginner-friendly Python tutorial focusing on K-Means clustering, a powerful technique used to group similar data points into distinct clusters. This invaluable tool helps us make sense of complex datasets, finding hidden patterns and associations without the need for a predetermined target variable. This comes in handy, especially when dealing with data whose similarities and differences aren’t immediately apparent.

Divided into two insightful sections, this blog post first delves into the theoretical foundation of the K-Means clustering algorithm. We’ll explore its real-world applications, its strengths, and its weaknesses, providing a comprehensive overview of what makes K-Means an essential tool in any data scientist’s toolkit.

In the second part of the blog, we switch gears and dive into a hands-on Python tutorial. Here, we’ll walk you through a practical example of K-Means clustering, using it to uncover three distinct spherical clusters within a synthetic dataset. To round up, we’ll put our model to the test, using it to predict clusters within a test dataset, and then we’ll visualize the results for easy understanding.

Whether you’re a seasoned data scientist or a beginner looking to dip your toes into the field, this blog post offers a simple and accessible introduction to cluster engineering with K-Means in Python. Follow along, and uncover the hidden potential of your data today!

Findings Clusters in Multivariate Data with k-Means

K-Means clustering is a prominent unsupervised machine learning algorithm utilized to partition datasets into a predefined number (‘k’) of distinct clusters, each brimming with similar data points. To begin, the algorithm identifies ‘k’ random data points which serve as the initial centroids – the central points representing each cluster. It then proceeds in an iterative fashion, continuously reassigning each data point to the centroid nearest to it, followed by updating each centroid to the average of the data points assigned to its cluster. This process repeats until the centroids no longer change positions or until a set maximum number of iterations is reached.

The underlying objective of the K-Means algorithm is to minimize the within-cluster sum of squares (WCSS), a metric indicating the cumulative distance between each data point within a cluster and its corresponding centroid. By reducing the WCSS, K-Means aims to form the most compact and clearly separable clusters.

The K-Means algorithm has garnered substantial popularity in the field of data science for its speed and simplicity in implementation. However, it isn’t without its limitations. It requires the number of clusters to be specified beforehand and operates under the assumption that all clusters are spherical and uniformly sized. In the following sections, we’ll delve into the intricacies of this powerful yet straightforward algorithm and discuss its use in real-world applications.

Understanding the Mechanics of K-Means Clustering Algorithm

At its core, K-Means clustering is a dynamic algorithm designed to simplify complex data patterns. This machine learning model is a champion of unsupervised learning, adept at grouping similar data points into a predetermined number (‘k’) of unique clusters.

Starting the process, the K-Means algorithm selects ‘k’ random data points, which act as the initial centroids or the central figures of the clusters. The algorithm then goes through a series of iterative steps, continually allocating each data point to its closest centroid, and recalibrating the centroid to be the mean of all data points that are assigned to its cluster. This cycle repeats until we achieve stable centroids, i.e., they stop moving, or until a pre-set maximum number of iterations is completed.

The fundamental goal of K-Means lies in minimizing the within-cluster sum of squares (WCSS). This term refers to the sum of the distances of each data point in a cluster to its centroid. By lowering WCSS, K-Means strives to construct compact clusters that are distinctly separate from each other.

In the illustration below, we assume a cluster with three cluster centers. K-Means carries out several steps to partition the data.

1. Initially, the algorithm k chooses random starting positions for the centroids. Alternatively, we can also position the centroids manually.
2. Then the algorithm calculates the distance between the data points and the three centroids. The data points are assigned to the closest centroid/cluster where the cluster variance increases the least.
3. Next, the algorithm calculates the Euclidean distance between the centroids and their assigned data points. The result is linear decision boundaries that separate the clusters but are not yet optimal.
4. From then on, the algorithm optimizes the centroids’ positions to lower the resulting clusters’ variance. Then, the previous steps are repeated: averaging, assigning the data points to clusters, and shifting the centroids.

The process ends when the positions of the centroids do not change anymore.

How many Clusters?

Prerequisites

Before beginning the coding part, make sure that you have set up your Python 3 environment and required packages. If you don’t have an environment, consider the Anaconda Python environment. To set it up, you can follow the steps in this tutorial.

Also, make sure you install all required packages. In this tutorial, we will be working with the following standard packages:

• pandas
• NumPy
• matplotlib

This article uses the k-means clustering algorithm from the Python library Scikit-learn. We also use Seaborn for visualization.

You can install these libraries using console commands:

• pip install <package name>
• conda install <package name> (if you are using the anaconda packet manager)

Step #1: Generate Synthetic Data

We start with the generation of synthetic data. For this purpose, we use the make_blobs function from the scikit-learn library. The function generates random clusters in two dimensions spherically arranged around a center. In addition, the data contains the respective cluster to which the data points belong. We use a scatterplot to visualize the data.

import pandas as pd
import numpy as np
import seaborn as sns
from matplotlib import pyplot as plt
from sklearn.model_selection import train_test_split as train_test_split
from sklearn.datasets import make_blobs
from sklearn.cluster import KMeans
from sklearn.preprocessing import StandardScaler
from sklearn.metrics import classification_report, confusion_matrix

# Generate synthetic data
features, labels = make_blobs(
    n_samples=400,
    centers=3,
    cluster_std=2.75,
    random_state=42
)

# Visualize the data in scatterplots
def scatter_plots(df, palette):
    fig, ax = plt.subplots(nrows=1, ncols=2, sharex=True, figsize=(20, 8))
    fig.subplots_adjust(hspace=0.5, wspace=0.2)


    ax1 = plt.subplot(1,2,1)
    sns.scatterplot(ax = ax1, data=df, x='x', y='y', hue= 'labels', palette=palette)
    plt.title('Clusters')

    ax2 = plt.subplot(1,2,2)
    sns.scatterplot(ax = ax2, data=df, x='x', y='y')
    plt.title('How the model sees the data during training')

palette = {1:"tab:cyan",0:"tab:orange", 2:"tab:purple"}
df = pd.DataFrame(features, columns=['x', 'y'])
df['labels'] = labels
scatter_plots(df, palette)

Step #2: Preprocessing

There are some general things to keep in mind when preparing data for use with K-Means clustering:

• Missing data and outliers: if we have missing entries in our data, we need to handle these, for example, by removing the records or filling the missing values with a mean or median. In addition, K-means is sensitive to outliers. Therefore, make sure that you eliminate outliers from the training data.
• Normalization: K-Means can only deal with integer values. So, either we map the categorical variables to integer values or use one-hot-encoding to create separate binary variables.
• Dimensionality reduction: In general, having too many variables in a dataset can negatively affect the performance of clustering algorithms. A good practice is to keep the number of variables below 30, for example, by using techniques for dimensionality reduction such as Principal-Component-Analysis.
• Scaling: Important to note is also that K-means require scaling the data.

Our synthetic dataset is free of outliers or missing values. Therefore, we only need to scale the data. In addition, we separate the class labels of the clusters from the training set and split the data into a train- and a test dataset.

# Scale the data
scaler = StandardScaler()
scaled_features = scaler.fit_transform(features)

X = scaled_features #Training data
y = labels #Prediction label

# Split the data into x_train and y_train data sets
X_train, X_test, y_train, y_test = train_test_split(X, y, train_size=0.7, random_state=0)

Step #3: Train a k-Means Clustering Model

Once we have prepared the data, we can begin the cluster analysis by training a K-means model. Our model uses the k-means algorithm from Python scikit-learn library. We have various options to configure the clustering process:

• n_clusters: The number of clusters we expect in the data.
• n_init: The number of iterations k-means will run with different initial centroids. The algorithm returns the best model.
• max_iter: The max number of iterations for a single run

We expect three clusters and configure the algorithm to run ten iterations.

# Create a k-means model with n clusters
kmeans = KMeans(
    init="random",
    n_clusters=3,
    n_init=10,
    max_iter=300,
    random_state=42
)

# fit the model
kmeans.fit(X_train)
print(f'Converged after {kmeans.n_iter_} iterations')

Converged after 4 iterations

Our model has already converged after four iterations. Next, we will look at the results.

Step #4: Make and Visualize Predictions

Next, we’ll be delving into the practical aspect of our Python tutorial by analyzing the performance of our trained K-Means model using synthetic data.

In the following Python code, we:

• Extract the cluster centers from the trained K-Means model and unscale them.
• Add the predicted and actual labels to our unscaled training data.
• Define a function, scatter_plots(), that creates two scatter plots: one for the predicted labels and another for the actual labels.
• Call this function, passing the training data, cluster centers, and a color palette as arguments.

Please note:

• We use a dictionary as a color palette to differentiate between clusters.
• The colors between the two plots may not match due to K-Means assigning numbers to clusters without prior knowledge of initial labels.

# Get the cluster centers from the trained K-means model
cluster_center = scaler.inverse_transform(kmeans.cluster_centers_)
df_cluster_centers = pd.DataFrame(cluster_center, columns=['x', 'y'])

# Unscale the predictions
X_train_unscaled = scaler.inverse_transform(X_train)
df_train = pd.DataFrame(X_train_unscaled, columns=['x', 'y'])
df_train['pred_label'] = kmeans.labels_
df_train['true_label'] = y_train

def scatter_plots(df, cc, palette):
    fig, ax = plt.subplots(nrows=1, ncols=2, sharex=True, figsize=(20, 8))
    fig.subplots_adjust(hspace=0.5, wspace=0.2)

    # Print the predictions
    ax2 = plt.subplot(1,2,1)
    sns.scatterplot(ax = ax2, data=df, x='x', y='y', hue='pred_label', palette=palette)
    sns.scatterplot(ax = ax2, data=cc, x='x', y='y', color='r', marker="X")
    plt.title('Predicted Labels')

    # Print the actual values
    ax1 = plt.subplot(1,2,2)
    sns.scatterplot(ax = ax1, data=df, x='x', y='y', hue= 'true_label', palette=palette)
    sns.scatterplot(ax = ax1, data=cc, x='x', y='y', color='r', marker="X")
    plt.title('Actual Labels')


# The colors between the two plots may not match.
# This is because K-means does not know the initial labels and assigns numbers to clusters
palette = {1:"tab:cyan",0:"tab:orange", 2:"tab:purple"}
scatter_plots(df_train, df_cluster_centers, palette)

The scatterplot above shows that K-Means found the three clusters. As a side note, the colors between the two plots do not match because K-means does not know the initial labels and assigns numbers to clusters.

Step #5: Measuring Model Performance

Next, we measure the performance of our clustering model. K-means is an unsupervised machine learning algorithm, which means that it is used to cluster data points into groups based on their similarity, without the use of labeled training data. However, we can compare the cluster assignments to the labels attached to the data and see if the model can predict them correctly. In this way, we can use traditional classification metrics such as accuracy and f1_score to measure the performance of our clustering model.

First, we unify the cluster labels as A, B, and C.

# The predictive model has the labels 0 and 1 reversed. We will correct that first.
#df_train['pred_test'] = df_train['pred_labels'].map({2:2, 1:3, 0:1})
df_eval = df_train.copy()
df_eval['true_label'] = df_eval['true_label'].map({0:'A', 1:'B', 2:'C'})
df_eval['pred_label'] = df_eval['pred_label'].map({0:'B', 1:'A', 2:'C'})
df_eval.head(10)

	x			y			pred_label	true_label
0	-9.007547	-10.302910	C			C
1	1.009238	7.009681	A			B
2	-6.565501	-6.466780	C			C
3	2.389772	7.727235	B			B
4	-5.422666	-2.915796	C			C
5	-12.024305	-7.846772	C			C
6	-4.006250	9.319323	A			A
7	-6.297788	6.435267	A			A
8	2.169238	3.325947	B			B
9	-5.140506	-4.205585	C			C

It is a common practice to create scatterplots on the predictions to visually verify the quality of the clusters and their decision boundaries. The following scatter plot shows the correctly assigned values and where our model was wrong.

# Scatterplot on correctly and falsely classified values
df_eval.loc[df_eval['pred_label'] == df_eval['true_label'], 'Correctly classified?'] = 'True'
df_eval.loc[df_eval['pred_label'] != df_eval['true_label'], 'Correctly classified?'] = 'False'

plt.rcParams["figure.figsize"] = (10,8)
sns.scatterplot(data=df_eval, x='x', y='y', color='r', hue='Correctly classified?')

The K-Means model correctly assigned most data points (blue) to their actual cluster. The few misclassified points are located at a decision boundary between two clusters (marked in orange).

# Create a confusion matrix
def evaluate_results(model, y_true, y_pred, class_names):
    tick_marks = [0.5, 1.5, 2.5]

    # Print the Confusion Matrix
    fig, ax = plt.subplots(figsize=(10, 6))
    results_log = classification_report(y_true, y_pred, target_names=class_names, output_dict=True)
    results_df_log = pd.DataFrame(results_log).transpose()
    matrix = confusion_matrix(y_true,  y_pred)
    model_score = score(y_pred, y_true, average='macro')

    sns.heatmap(pd.DataFrame(matrix), annot=True, fmt="d", linewidths=.5, cmap="YlGnBu")
    plt.xlabel('Predicted label'); plt.ylabel('Actual label')
    plt.title('Confusion Matrix on the Test Data')
    plt.yticks(tick_marks, class_names); plt.xticks(tick_marks, class_names)

    print(results_df_log)


y_true = df_eval['true_label']
y_pred = df_eval['pred_label']
class_names = ['A', 'B', 'C']
evaluate_results(kmeans, y_true, y_pred, class_names)

As we can see, the model has done a good job of grouping the labels into the attached classes.

Summary

algorithm, capable of parsing intricate datasets into discrete, non-overlapping clusters. With this guide, you should have a clear understanding of how this algorithm operates, as well as its unique strengths and potential limitations. Remember, k-Means excels when dealing with spherical clusters but may struggle with clusters of more complex shapes.

We walked through how to implement the k-Means algorithm in Python, using it to identify spherical clusters within synthetic data. Moreover, we explored different methods to evaluate and visualize a clustering model’s performance, providing you with valuable tools to effectively analyze and group your data.

Whether it’s anomaly detection in time-series data or customer segmentation, k-Means can be a powerful tool in your data science arsenal. If you’re interested in anomaly detection, feel free to explore my recent article on the subject, written with Python enthusiasts in mind. Armed with this knowledge, you’re ready to embark on your own data exploration journey using k-Means clustering.

If you are interested in this topic, check out my recent article on anomaly detection with Python. And if you have any questions, please ask them in the comments.

Did you know that customer segmentation is an area where real-world data can be prone to bias and unfairness? If you’re concerned that your models may reflect the same bias, check out our latest article on addressing fairness in machine learning with fairlearn.

Sources and Further Reading

The links above to Amazon are affiliate links. By buying through these links, you support the Relataly.com blog and help to cover the hosting costs. Using the links does not affect the price.

Related Articles on Clustering

1. Hierarchical clustering for customer segmentation in Python: We present an alternative approach to k-means that can determine the number of the clusters themselves and works well if the distributions of the groups in the data is more complex.
2. Clustering crypto markets using affinity propagation in Python: This article applies cluster analysis to crypto markets and creates a market map for various cryptocurrencies.

The post Cluster Analysis with k-Means in Python appeared first on relataly.com.
